Key Takeaways

1. New Model Introduction: Asus has launched the ROG Azoth 96 HE, a new 96% mechanical keyboard model featuring Hall Effect magnetic switches.

2. Improved Polling Rate: The keyboard supports an 8,000 Hz polling rate in both wired and wireless modes, enhancing responsiveness.

3. Hall Effect Switches: It features customizable ROG HFX V2 switches, allowing users to adjust actuation points from 0.1 to 3.5mm in 0.01mm increments.

4. Premium Build Quality: The keyboard includes a silicone gasket mount, pre-lubed stabilizers, and multiple dampening materials for improved sound and comfort.

5. No Release Date Yet: Asus has not announced the release date or pricing for the ROG Azoth 96 HE, but it is expected to be at the higher end of the price range.

Asus has added a new 96% model to its Azoth mechanical keyboard series. After introducing the first Azoth in 2023 (current price: $154.99 at Amazon), the brand has launched two more versions, both featuring standard mechanical switches in the same 75% size. The latest ROG Azoth 96 HE enhances this design by incorporating Hall Effect magnetic switches for better accuracy while also including a numpad and additional system keys.

Enhanced Features

In addition to the new layout, Asus has also improved the polling rate for this keyboard. The ROG Azoth 96 HE supports an impressive 8,000 Hz polling rate in both wired and wireless modes, thanks to the 2.4 GHz ROG SpeedNova 8K adapter. Bluetooth and USB connections are also available, allowing users to link up to five devices at once. The keyboard keeps the 1.47-inch OLED touchscreen and multifunction knob that were featured in earlier Azoth versions.

Hall Effect Switches

The standout feature of this model is the upgrade to Hall effect switches. Unlike previous models that utilized ROG NX switches, the new ROG Azoth 96 HE is equipped with ROG HFX V2 switches, similar to those found on the ROG Falcata split mechanical keyboard. These magnetic switches with ROG Hall sensors allow users to customize the actuation point and benefit from advanced functionalities like Rapid Trigger and Speed Tap, which is Asus’s version of Razer’s Snap Tap.

Customization options for the actuation point range from 0.1 to 3.5mm, with precise tuning available in 0.01mm steps for better keystrokes.

Premium Build Quality

Internally, the ROG Azoth 96 HE features high-quality aspects such as a silicone gasket mount with pre-lubed stabilizers for the space bar and other longer keys. It also employs six layers of dampening materials, including Poron and IXPE, aimed at enhancing sound quality and providing a more comfortable typing experience. Additionally, the keyboard is constructed with a metal top frame, giving it a sophisticated appearance.

Asus has yet to announce a release date or pricing for this model. However, since the original came out at $250 with a 75% layout and lacked Hall effect switches, it’s likely that the ROG Azoth 96 HE will be positioned at the upper end of the pricing scale.

Source:
Link

Key Takeaways

1. Keychron is launching the Q16 HE 8K, the world’s first keyboard made entirely of ceramic, including chassis and keycaps.
2. The keyboard will feature Hall Effect magnetic switches and a compact 65% QWERTY layout, targeting gamers and enthusiasts.
3. It is expected to debut on Kickstarter in October, but pricing details have not been revealed yet.
4. The Q16 HE 8K will offer advanced features like rapid trigger and dynamic keystrokes, customizable through Keychron’s web-based software.
5. It will be available in black and white color options, providing a unique typing experience with a “thocky” sound and smoother feel.

Keychron has been really active with its recent keyboard launches. Back in June, they introduced two budget-friendly mechanical keyboards, followed by the Keychron K9 Max, which features low-profile switches. More recently, they unveiled a special edition DayZ-themed Lemokey P1 HE. Now, the brand is stepping into the ceramic keyboard market with a new 65% model.

Upcoming Launch

The company shared news on X (which used to be known as Twitter) about their forthcoming keyboard, the Q16 HE 8K. Keychron claims this will be the first keyboard in the world that is made entirely of ceramic, including both the chassis and the keycaps. It will also come equipped with Hall Effect magnetic switches, which are quite popular in premium gaming keyboards, along with a standard QWERTY layout in a compact 65% size.

Pricing and Availability

The Keychron Q16 HE 8K is expected to debut on Kickstarter in October, although the company hasn’t disclosed any pricing information yet. Interested consumers can register for launch updates to get more information as the release date draws nearer.

Design and Features

Images shared on X and Prelaunch suggest that the Q16 HE 8K has many appealing features, with its fully ceramic construction being the highlight. The entire keyboard, from the chassis to the keycaps, is made of high-quality ceramic materials. Keychron states that this makes the keyboard pleasant to touch, produces a “thocky” sound, and offers a smoother typing feel. The keycaps are styled in a Cherry profile and complement the north-facing backlight for a more vibrant RGB experience.

Performance Specs

Internally, the Q16 HE 8K is powered by Keychron’s Ultra-fast Lime Magnetic Switches, which are the same ones found in the Lemokey L5 HE 8K. These Hall-effect linear switches use TMR sensors, allowing for actuation adjustments down to 0.1 mm in 0.01 mm increments. With an impressive 8,000 Hz polling rate, competitive gamers should find plenty of advantages. The switches are hot-swappable, and Keychron includes pre-lubed plate-mounted stabilizers to ensure stability during use.

Advanced Features

As a Hall effect keyboard, it supports many advanced features, including rapid trigger, dynamic keystrokes that can map up to four different actions to one key, and Keychron’s own version of Razer Snap Tap for precise strafing. Users can modify most of these options through the company’s web-based software. While testing ceramic keyboards has typically involved purchasing ceramic keycap sets from brands like Cerakey, the Q16 HE 8K will provide gamers their first opportunity to try a full ceramic keyboard.

The Keychron Q16 HE 8K will launch on Kickstarter sometime in October and will come in both black and white color options.

Source:
Link

Key Takeaways

1. Limited Tactile Switch Options: Currently, the main tactile switch options for Hall effect keyboards are Glorious Panda HE and AEboards Raeds HE switches, with limited compatibility.

2. Gateron’s New Switch: Gateron is introducing the Magnetic Jade Emerald tactile switch, which is expected to be broadly compatible with various Hall effect keyboards.

3. Pricing and Specs Anticipation: While exact pricing and specifications are not yet revealed, an announcement is anticipated during Gamescom or IFA, with a likely price similar to the Jade Pro switches.

4. Design Innovations: The Magnetic Jade Emerald switch features a round stem for better stability and may include nubs to reduce friction, potentially enhancing smoothness in keystrokes.

5. User Preference for Tactile Feedback: Despite the popularity of linear switches for Hall effect keyboards, many users are still seeking tactile feedback, indicating a demand for more tactile switch options.

If you own a Hall effect gaming keyboard and are in search of tactile switches, your main options right now are the Glorious Panda HE switches, which have very limited compatibility—seemingly only working with Glorious and Keychron HE keyboards—or the AEboards Raeds HE switches. The latter are labeled as tactile, but they achieve this by using rubber domes to mimic the Topre switch designs.

Gateron Enters the Market

Gateron is stepping into the scene with their new Magnetic Jade Emerald tactile switch. This switch appears to be a more broadly compatible Hall effect option for keyboards such as the Wooting 80HE and Iqunix EZ63. While Gateron has only given a sneak peek of this new switch on X, we can deduce a few details from the image they shared.

Anticipated Pricing and Specs

Exact cost and specifications haven’t been disclosed yet, but it seems that an announcement during Gamescom or IFA is very probable, as Gateron mentioned that the new switch will be available “soon.”

Considering that the Gateron Magnetic Jade Emerald switch is part of the same series as the Jade Pro (currently priced at $56 for 70 switches on Amazon) switches, which we lauded in our Iqunix EZ3 review, we can infer that it shares the same design features, including a closed-bottom design, a PC top housing, a nylon bottom housing, and a POM stem. It will likely maintain the same 3.5 mm total travel as the Jade Pro and gaming switches.

Design Innovations

However, the tactile Magnetic Jade Emerald switch seems to differ from its linear counterparts, especially in the stem design. The round stem deviates from Gateron’s typical HE switches and could offer enhanced stability when pressing keycaps off-center. Upon examining the top housing closely, it appears to incorporate the same small nubs around the stem that Gateron has recently utilized on the Magnetic Spark switches. These nubs are designed to reduce friction between the stem and the top housing, leading to smoother keystrokes.

It is still uncertain if Gateron will also adopt the dual-drive modular structure from the Spark, which separates the stem into two components and allegedly removes the impact of stem wobble on the Hall sensor’s precision.

User Preferences in Tactile Feedback

Hall effect gaming keyboards have primarily been associated with linear switches, which is generally understandable. The analog controls enabled by HE technology, such as adjustable actuation distance, rapid trigger, and SOCD, benefit from linear movement. Having precise control over the switch’s position during travel facilitates the use of these features. Nevertheless, many HE keyboard users still desire a more classic tactile feedback that can only be achieved with tactile switches.

Source:
Link

Key Takeaways

1. The Keychron K8 HE features Gateron Double-Rail Magnetic Nebula switches for excellent stability and minimal wobble.
2. It adopts a traditional TKL layout, making it familiar for gamers, with customizable function rows and a dedicated navigation cluster.
3. The keyboard supports deep software customization through the Keychron Launcher web app, allowing for macros.
4. It offers tri-mode connectivity (Bluetooth, 2.4 GHz, and USB-C), with a 1,000 Hz polling rate for optimal gaming performance.
5. The K8 HE is priced at $129.99 for the Standard Edition and $139.99 for the Special Edition, currently available on the Keychron website.

We took a look at the Keychron K4 HE, a wireless Hall-effect gaming keyboard, and we loved its beautiful Cherry wood details, great customizability, and comfy typing experience. Now, Keychron has introduced the K8 HE, which brings all those same great features to the popular TKL (tenkeyless) design.

Impressive Features

Similar to the Keychron K4 HE (currently priced at $144.99 on Amazon), the K8 HE is equipped with Gateron Double-Rail Magnetic Nebula switches, providing excellent stability for the keycaps with nearly no wobble. Moreover, the K8 HE Special Edition showcases the same OSA-profile double-shot PBT keycaps, while the Standard Edition has shine-through Cherry-profile keycaps that let the north-facing RGB backlighting glow brightly.

Traditional Layout

Unlike the K4 HE, the K8 HE adopts a more classic TKL layout that many gamers will recognize. The navigation cluster is positioned above the arrow keys, just to the right of the main alpha keys, and the function row is divided into groups of four keys. The K8 HE also includes the same aluminum plate material and allows deep software customization through the Keychron Launcher web app, making it one of the few Hall-effect gaming keyboards that can support macros, unlike the Wooting 80HE and Iqunix EZ63.

Connectivity Options

The K8 HE offers tri-mode connectivity, which includes Bluetooth, 2.4 GHz, and USB-C wired options, and the 2.4 GHz mode comes with a quick 1,000 Hz polling rate for optimal gaming performance. Additionally, the K8 HE has a dedicated macOS mode, featuring a hardware switch to toggle between operating systems, and it includes extra macOS keycaps in the package to ensure a seamless experience.

Currently, the Keychron K8 HE is only available on the Keychron website, priced at $129.99 for the Standard Edition or $139.99 for the Special Edition, but it is expected to be listed on Amazon in the future.
